EVE LF230 Datasheet
Overview
Grade A Cells with 1 year in-house warranty for manufacturer defects
1 Busbar and set of 2 nuts/bolts included with each cell.
SPECIFICATIONS:
| Manufacturer: |
EVE Energy |
| Model: |
LF230 |
| Form: |
Prismatic |
| Nominal Capacity: |
230Ah |
| Nominal Voltage: |
3.2V |
| Cutoff Voltage Charge/Discharge: |
3.65V/2.5V |
| Max Continuous Charge/Discharge Current: |
1C/1C |
| Max Pulse (30s) Charge/Discharge Current: |
2C/2C |
| Cycle Life: |
3,500 cycles |
| Protected: |
NO, UNPROTECTED. This cell is unprotected and intended for use in protected battery packs only and NOT individually or as a standalone product. In order to operate safely it must have additional protection in the form of a PCB (circuit board) or BMS (battery management system), which is not included. |
| Approximate Dimensions: |
173.93mm x 53.85.0mm x 207.3mm |
| Approximate Weight: |
4110g |
| Country of Origin: |
China |
| Specification Datasheet: |
EVE LF230 Datasheet
|
Safety Guidelines & Warnings
⚠️ IMPORTANT SAFETY NOTICE ⚠️
EVE LF280K 280Ah LiFePO4 battery requires proper handling and knowledge to ensure safe usage.
Failure to follow safety guidelines may result in fire, explosion, serious injury, or property damage.
General Safety Guidelines
✔ Only purchase and use if you fully understand lithium-ion battery safety.
✔ Always charge in or on a fire-resistant surface—never leave batteries charging unattended.
✔ Use only a compatible smart charger designed specifically for this type of battery.
✔ Store batteries in a protective case—never carry them loose in a pocket, bag, or purse.
✔ Keep away from metal objects (keys, coins, tools) to prevent short circuits.
✔ Use only within manufacturer-listed specifications and in protected battery packs.
✔ Resellers must provide these warnings to all customers.
🚫 Prohibited Uses & Handling
⛔ DO NOT use this battery in e-cigarettes, vaporizers, or similar devices.
⛔ DO NOT mix old and new, or used and unused batteries.
⛔ DO NOT short circuit, puncture, cut, crush, incinerate, or modify the battery.
⛔ DO NOT use if the battery wrapper is torn or damaged in any way.
⛔ DO NOT overcharge or over-discharge—this can lead to battery failure.
⛔ DO NOT expose the battery to liquids, extreme heat, or direct sunlight.
⛔ DO NOT solder directly—only use spot welding for battery pack assembly.
⚠ User Responsibility & Risk Acknowledgment
-
The user assumes full responsibility for proper handling, charging, and storage.
- Misuse or mishandling may result in serious injury or damage.
-
No guarantee of compatibility with any specific device is provided.
- Usage of this battery is at your own risk.
By purchasing and using the 3.2V 280ah LiFePo4 Battery, you acknowledge and agree to follow all safety guidelines.
Failure to comply may result in hazardous consequences. Prior knowledge of lithium-ion battery safety is required before purchase.
Stay safe and handle responsibly. 🔋
